KVV Control Cable 450/750V PVC Insulated PVC Sheathed Multi Core Control Cable Manufacturer
KVV control cable is a PVC insulated and PVC sheathed control cable designed for signal transmission, monitoring circuits, and control systems. It is widely used in industrial plants, power stations, substations, manufacturing facilities, and building automation projects.
Manufactured according to IEC, GB, and BS standards, KVV cables provide stable electrical performance, reliable signal transmission, and excellent durability in fixed installation environments. These cables are suitable for control, protection, and measurement circuits with rated voltages up to 450/750V.
Whether for industrial automation systems, power distribution networks, or infrastructure projects, KVV control cables offer a cost-effective and dependable solution for long-term operation.
Product Structure
KVV Control Cable Construction
Structure Composition
- Copper Conductor
- PVC Insulation
- Multi-Core Twisted Assembly
- PVC Inner Filling (Optional)
- PVC Outer Sheath
Technical Specifications
| Parameter | Specification |
| Product Type | KVV Control Cable |
| Rated Voltage | 450/750V |
| Conductor Material | Copper |
| Insulation Material | PVC |
| Sheath Material | PVC |
| Core Number | 2-61 Cores |
| Conductor Size | 0.5 mm² - 10 mm² |
| Operating Temperature | -15°C to +70°C |
| Installation Temperature | ≥0°C |
| Bending Radius | ≥6 × Cable Diameter |
| Standard | GB/T 9330, IEC, BS |
| Flame Retardant Option | Available |
| Shielded Version | KVVP Available |
Typical Applications
Power Industry
KVV control cable is commonly used in:
- Power stations
- Transformer substations
- Distribution panels
- Protection and monitoring systems
- Switchgear cabinets
Industrial Automation
Industrial facilities require dependable control cables for:
- PLC systems
- Automated production lines
- Conveyor systems
- Packaging machinery
- Industrial control cabinets
Why Choose KVV Cable?
- Strong mechanical performance
- Easy routing and installation
- Suitable for long-term operation
Quality Assurance
Every batch of KVV control cable undergoes strict quality inspection.
Available Cable Types
| Model | Description |
| KVV | PVC Insulated PVC Sheathed Control Cable |
| KVV22 | Steel Tape Armored Control Cable |
| KVVR | Flexible Control Cable |
| KVVP | Shielded Control Cable |
| KVVP2 | Copper Tape Shielded Control Cable |
| KVVRP | Flexible Shielded Control Cable |
Certifications & Standards
Manufactured according to:
- IEC Standards
- GB/T Standards
- BS Standards
- CE Requirements
- ISO 9001 Quality Management System
Available upon request:
- Technical Datasheet
- Product Catalog
- Test Reports
- Factory Inspection Documents
FAQ
What is KVV cable used for?
KVV cable is mainly used for control, monitoring, signaling, and protection circuits in industrial electrical systems.
What is the difference between KVV and KVVP cable?
KVVP cable contains a shielding layer that improves protection against electromagnetic interference, while KVV is a standard unshielded control cable.
Can KVV cable be installed outdoors?
Yes. It can be used outdoors in protected environments. For underground or mechanically demanding installations, KVV22 armored control cable is recommended.
What voltage is KVV control cable rated for?
The most common rated voltage is 450/750V.
What is the service life of KVV cable?
Under normal operating conditions, KVV control cable can provide 20–30 years of service life.
